Model: SW-2100
Reliable and easy to operate is suitable for hospitals and ophthalmic clinics for daily diagnostic use.
The SW-2100 A/B Scaner combines A and B scan functions for comprehensive eye examination. It is designed to diagnose intraocular diseases and measure key ocular parameters.
A Scan:
Used to measure anterior chamber depth, lens thickness, and axial length, and to calculate the intraocular lens (IOL) power for implantation.
B Scan:
Provides normal, vitreous body enhancement, and retina observation modes. It helps detect and evaluate vitreous opacity, retinal detachment, eye base tumors, and other eye conditions. The scan clearly displays the location, shape, and range of lesions, as well as their relationship with surrounding tissues.
The SW-2100 AB scanner provides accurate eye diagnosis through high-resolution imaging and Easy-to-use workstation software, friendly userinterfacelndustry-leadingimage quality and measurement accuracySupport DICOM 3.0.
The SW-2100 AB scanner provides accurate eye diagnosis through high-resolution imaging and allowing probesto be mixed and matched to meet different needs. Ensuring a smooth and streamlined diagnostic process.
| A Scan | B Scan | ||
| Frequency | 10MHz, with LED | Frequency | 10MHz/20MHz (optional) ,Magnetic driven, noiseless |
| Depth | 40mm | Scanning Mode | Sector Scanning |
| Precision | ±0.05 mm | Magnify | Multi continuous magnification,Real-Time magnification |
| Measurement | Anterior chamber depth, lens thickness, | Resolution | Lateral ≤0.3mm; Vertical≤0.2mm |
| vitreous body length, total length and average | Geometry position precision | Lateral ≤10%; Vertical≤5% | |
| Depth | 60mm | ||
| Gain of probe | 30dB-105dB | ||
| Eye mode | Phakic / Aphakic / Dense / Various IOL | Scanning Angle | 53° |
| IOL Formula | SRK-II, SRK-T, HOFFER-Q, HOLLADAY,BINKHORST-II, HAIGIS | Gray Scale | 256 |
| False Color | Multi colors. OCT | ||
| measurement type | Multigroup distances, perimeters and areas | ||
| Stat. Calculation | Average and standard deviation | Movies | 100 images movie review, AVI JPG format image output |
| Store | 10 Scanning results for each eye | Image postprocessing | multiple curves processing, Pseudo-color processing curve |
| Display Mode | B, B B, B A, A | ||
| Hint | Preset keyword | ||
| Case Search | Multi-keywords | ||
| Working Platform | Windows XP, VISTA, WINDOWS7 | ||
| User-defined report template | with | ||
