Model: GM-100
The GM-100 Lens Grooving Machine is designed for accurate manual grooving of lenses used in semi-rimless frames. Manual adjustment allows precise control of groove depth and position, making it suitable for optical labs and eyewear workshops handling daily lens processing tasks.
International design concept of combination offashion and personality,groove depth, position adjustment (front - middle - back).
Adapts to slight variations in lens shape and thickness, reducing vibration and improving groove accuracy and consistency.
| Item | Specification |
|---|---|
| Model | GM-100 |
| Voltage / Frequency | 220V / 50Hz or 110V / 60Hz |
| Power | 80W |
| Motor | Low-noise Electric Motor (100 Watt) |
| Lens Thickness Range | 1.5 mm – 11 mm |
| Lens Diameter Range | 18 mm – 70 mm |
| Groove Width | 0.65 mm |
| Adjustable Groove Depth | 0 – 0.7 mm |
| Limited Beveling Sizes | For Oblong Corner Lenses: p22x50 |
| For Round Corner Lenses: @22×56 |
